RuiDa Laser Controller

  RDLC320-A is a controller especially for laser engraving/cutting,based on floating 32-bit DSP+FPGA architecture with high performance.It can finish large-scale complex motion control algorithm to achieve the continuous path control and position control of multi-axis movement,and energy tracking control,keeping the laser energy balance at any speed point.Large-scale logical gate array FPGA can complete the complex communication protocol and flexible IO extension.Fast communicate transmission and easy to operate. Check On Aliexpress Check On Ebay Parameter 1,Digital laser control signals 1,Differential output,TTL level,20mA,drive capability PWM frequency 2.5K-50K for adjustable PWM duty ratio is 2%-98%,adjustable PWM value is up to 4.5V Analog laser control signal:0-5V tracing adjustable automatically Motor control signal;differential output,TTL level,drive capability 20mA Motor control pulse frequency:Max 400KHZ USB:Max transmission rate is 12Mbps;;the longest distance is 5 meters Int

  Features Lightburn is layout, editing, and control software for your laser cutter. With Lightburn you can: Import artwork in a variety of common vector graphic and image formats(including Al. PDF, SVG, DXF, PLT, PNG, JPG, GIF, BMP) Arrange, edit, and even create new vector shapes within the editor, with powerful fea tures like offsetting, boolean operations welding, and node editing Apply settings like power, speed, number of passes, cut order, brightness contrast, dithering mode, and much more Send the result directly to your laser cutter Lightburn is a native application written for Windows, Mac OS, and Linux. System Mac OS Windows Language Support Designed to Work With Laser LightBurn talks directly to your laser,without the use of additional software support most Ruida. Trocen, and Gcode based controllers.  Supported Gcode controllers include Grbl Smoothieware, Grbl-lpc, and Marlin. Supported Ruida controllers include the RDC6442G/S, RDC6445G, RDC6332G RDLC-320A, and R5-DSP. Supp

  The RDC6432G system is the latest laser engraving cutting control system. True color TFT screen, man-machine operating system.1-way independent adjustable laser power control.Multi-channel general dedicated IO control. Better and better motion control functions. Check On Aliexpress Check On eBay Parameter Digital laser control signal; TTL level output, 50ma drive capability; The PWM frequency is adjustable from 2K to 50K; PWM duty cycle is adjustable from 1% to 99% Motor control signal OC output, 300ma drive capability Motor control pulse frequency is up to 500KHZ; USB maximum transmission rate of 12M the longest distance of 5 meters; Linear/ circular/b- -spline interpolation accuracy+-0.55 pulse Size Software RDWorks V8 Diagram Certification Software and Manual RDWorks V8 Setup 8.01.54-20210513 RDC6432G-control-system-user-manual-V1.1 Download Ruida-RDC6432G-Wiring-Diagram Download

  "RDC6442S" Ruida RDC6442S/G Ruida RDC Classic Design RDC6442G have 3.5 inch Colorful Screen ,Free Software RDWorks,Double-Head Linkage(644XS) Application area: laser cutting, laser engraving, laser welding etc. Power:+24V, >2A Temperature: 0~50 ℃, humidity is not greater than 70% Check On Aliexpress Check On eBay Ruida RDC6442G/S  system is a new generation system for 4-Axis control of laser engraving and cutting. Digital Laser Control Signals: (1) TTL level output, 50 mA, Drive Capability (2) PWM frequency 2K-50K for adjustable (3) PWM duty ratio is 1% ~ 99%, adjustable (4) PWM value is up to 5.0 V One-Way 24V Power Supply, >2A Motor Control Signal: Common-anode Output, Drive Capability 20 mA. Motor control pulse frequency: Max.500KHZ 10/100M Ethernet + USB 2.0 Control. Interpolation: Linear/circular arc/B spline, accuracy + / – 0.5 pulse Output: 4-channel, photoelectric isolated OC gate output, the max. drive capability 500mA drive capability (with follow-current pr

  Support up to channels of servo/stepping motor control Support 1 way extended serial port, which can communicate with EPLC-400. wireless handheld devices (BWK201R, BWK301R), and other devices with RS232 standard interface. Support 4 OC gate outputs, which can directly drive 5v/24 relays Support mobile APP Support double-head electric mutual movement control and over-format cutting Support double-head- asynchronous processing Support processing methods such as large format vision, mark pont vision cutting and projection cutting Support controller and HMI firmware updating by U disk Startup screen can be upgraded through software Check On Aliexpress Parameter 4 motor interfaces, maximum output is 400KHZ frequency: drive capacity 20MA. common anode interface Onboard 128M memory. The maximum USB transfer rate is 12M, and the longest distance is 5 meters. The maximum transmission rate of the network cable is 100M, and the maximum transmission distance is 200M; Linear/arc/B-spline interpol

  It is a wireless WIFI convertor, based on this terminal, user can cooperate with RUIDA motion controller to establish the wireless control LAN based on WIFL, and to get rid of thewired networking connection absolutely, which can reduce the user cost and increase flexibility. Check On Aliexpress Check On eBay Internet connection Configured Computer Choose the WIFI name”TP-LINK”,wireless connection showed “connected”,which means the computer and RD-WIFI smart module connected successfully. Phone control RD-WIFI-Wireless-Networking-Instruction Download
